Description

• Product Type: Flush Button
• Height:
• Style: Modern
• Mounting: Wall
• Brand: Geberit
• Collection: Type10
• Shape: Round
• Easy to install and use
• Images are shown for illustration purposes only
• Protection degree: IP45
• Nominal voltage: 85?240 V AC
• Operating voltage: 12 V DC
• Mains frequency: 50?60 Hz
• Power consumption standby: 0.15 W
• Interval flush, adjustment range min.: 1?168 h
• Interval flush, factory setting: 24 h
• Interval flush time, adjustment range: 1?200 s
• Interval flush time, factory setting: 5 s
• For manual remote flush actuation of Omega concealed cisterns 12 cm using a touchless IR button
• For releasing a dual flush
• For installation in solid and drywall constructions with flush-mounting box
• For installation in bathroom furniture with counternut
• Suitable for less-abled installation
• For Omega concealed cisterns 12 cm
• Touchless manual flush actuation
• Touchless flush actuation for single or dual flush by moving hand toward sensor
• Dual flush via flush plate can be triggered from above or from the front
• Can be combined with flush plates Omega20 to Omega60 or Geberit cover plates
• Power supply via external power supply unit
• Transformation of mains voltage to extra-low voltage, 12 V DC
• Operation with extra-low voltage, no mains voltage in cistern
• With push-fit connection with cross-polarity protection
• Interval flush preset
• Adjustable interval flush
• Device settings and operation with mobile device via integrated Bluetooth? interface
• Compatible with Geberit Control App
• Wired networkable with Geberit gateway via GEBUS converter
• Wirelessly connectable with Geberit Gateway via Bluetooth
• Compatible with Geberit Connect
• Low-noise lifting mechanism
• Electrical lifting device, self-calibrating
