Geberit Type20 Pneumatic Urinal Flush Plate
- Description
- Additional information
- Store Policies
- Enquiries
Description
- Product Type: Flush Plate
- Brand: Geberit
- Collection: Type20
- Height: 130mm
- Width: 130mm
- Depth: 9mm
- Style: Modern
- Shape: Square
- Button Shape: Square
- Mounting: Wall
- Material: Plastic
- Easy to install and use
- Images are shown for illustration purpose only
- Flow pressure: 1?8 bar
- Test pressure, water max.: 16 bar
- Test pressure, air / inert gas max.: 3 bar
- Operating temperature, water max.: 30 ?C
- Actuation force max.: 12 N
- Flow rate at 1 bar without flow limiter: 0.3 l/s
- Flow rate at 1 bar with flow limiter: 0.18 l/s
- Minimum flow pressure: 1 bar
- Relative humidity: ? 100 %
- Calculated flow rate: 0.22 l/s
- Flush time, adjustment range: 4 / 8 / 12 s
- For manual flush actuation of urinals
- For Geberit frames for urinal with front actuation
- For installation in installation sets for Geberit urinal flush controls (from year of manufacture 2009)
- Flush plate with securing bar
- Flush time setting with air nozzles (pneumatic)
- Low flush actuation force
- Short stroke movement
- Flush actuation when the actuator button is released
- Flush volume can be reduced to 0.5 l per flush with regulating screw of installation set
Additional information
| Colour | Black/Matt Black, Matt Black/Black, Matt Chrome/Bright Chrome |
|---|---|
| Brand | Geberit |
| Collection | |
| Height | |
| Width | |
| Depth | |
| Style | |
| Shape | |
| Button Shape | Square |
| Mounting | |
| Material | |
| Product Type |
