Description

• Collection: Raindance E
• Product Type: Exposed Shower kit
• Number of Outlets: 3
• Style: Modern
• Brand: Hansgrohe
• Consists of: overhead shower, hand shower, thermostatic bath mixer, shower hose, shower holder
• overhead shower Raindance E 360 Air
• shower head size overhead shower: 360 x 190 mm
• spray type overhead shower: RainAir
• overhead shower angle adjustable
• shelf made of safety glass
• Shelf colour: mirror glass
• Maximum flow rate (at 3 bar): 20 l/min
• flow rate RainAir 15 l/min at 3 bar
• spray type hand shower: RainAir, Rain, Whirl
• Min. operating pressure: 1,3 bar
• Max. operating pressure: 10 bar
• Bar width: 44 mm
• shower arm length overhead shower: 380 mm
• CoolContact thermostat: Prevents the housing from heating up, making showering even safer
• thermostat Ecostat Select
• safety stop at 40C
• adjustable hot water limitation
• outlets controlled via volume control/diverter and may not be used simultaneously
• exposed design allows easy installation, all working parts are outside of the wall
• Connection dimension 1/2″
• Connection thread “
• Centre distance 150 mm 12 mm
• Intrinsically safe against backflow
• Stand pipe: 1400 mm
• in case of installation on existing G connections, adaptor no. 02026000 must be used
• Images shown are for illustration purpose only
