Description

• Collection: Vernis Shape
• Product Type: Exposed Shower kit
• Colour: Chrome
• Number of Outlets: 3
• Style: Modern
• Brand: Hansgrohe
• Consists of: overhead shower, hand shower, thermostatic bath mixer, shower hose, slider, shower bar
• overhead shower Vernis Shape 230 1jet
• shower head size overhead shower: 230 x 170 mm
• spray type overhead shower: Rain
• overhead shower angle adjustable
• Maximum flow rate (at 3 bar): 20 l/min
• flow rate Rain 8.7 l/min at 3 bar
• spray type hand shower: Rain, IntenseRain
• Flow rate of hand shower (at 3 bar): 8.7 l/min
• Min. operating pressure: 1 bar
• Max. operating pressure: 10 bar
• Shower bar diameter: 19 mm
• height-adjustable slider with locking push-button slider
• shower arm length overhead shower: 426 mm
• thermostat Vernis
• safety stop at 40C
• adjustable hot water limitation
• outlets controlled via volume control/diverter and may not be used simultaneously
• exposed design allows easy installation, all working parts are outside of the wall
• Connection dimension 1/2″
• Connection thread “
• Centre distance 150 mm 12 mm
• Intrinsically safe against backflow
• Stand pipe: 1424 mm
• Images shown are for illustration purpose only
